| 60Tare Weight |
6000KG |
| Loading Weight |
10-20 Ton |
| Main beam |
Material: Q345B fabricated carbon steel; Type: straight type; Height: 480mm; Upper plate: 14mm: Bottom plate: 16mm Middle plate:8mm Process: welded by automatic submerged-acr |
| cross beam |
10# C type: Q235 |
| Twist lock |
12 units |
| King pin |
50# |
| Axle |
Brand: Xinya; Capacity: 13T16P QTY: 3 units |
| Tyre |
Brand: Linglong; Type: 12R22.5-18PR: double mounted: QTY: 12 units |
| Rim |
22.5*9.0-14. 12 units or 6 units |
| Landing gear |
28T total Lifting capacity and 50T static capacity; double speed; large pad feet; |
| Suspension |
Mechanical system with beams equaliser |
| Leaf spring |
Germany type; Qty: 90mm13mm10+10+10 layers |
| Brake system |
Type: Dual line braking system Brake air chamber: 6 in total, T30/304 + T302 Air tank: 40L*2 unit ABS: none |
| Electric system |
24V LED light; waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
